Product code: 1393840
Available quantity 40
| Warranty: | 36 |
| Manufacturer: | ASROCK |
| Technical specification | |
|---|---|
| ATX Power connector (24-pin) | Yes |
| Audio chip | Realtek ALC897 |
| Audio output channels | 7.1 channels |
| Audio-In | 1 |
| Audio-Out | 1 |
| BIOS memory size | 256 Mbit |
| BIOS type | EFI AMI |
| Chipset | AMD B650 |
| Compatible processor series | AMD Ryzen™ 7 |
| Component for | PC |
| CPU fan connector | Yes |
| Depth | 226 mm |
| DisplayPort | 1 |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
| ECC сompatibility | Non-ECC |
| EPS power connector (8-pin) | Yes |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Form Factor | Micro-ATX |
| Frequency speed | 6400 |
| Front panel audio connector | Yes |
| Full Description Line | AMD B650|SAM5|Micro-ATX|DDR5|6400 MHz|Memory slots 2|1xPCI-Express 4.0 1x|2xPCI-Express 4.0 16x|1xM.2|1xHDMI|1xDisplayPort|1xAudio-In|1xAudio-Out|1xMicrophone|4xUSB 2.0|2xUSB 3.2|1xUSB-C|1xRJ45|SATA|Video Depending on CPU|Audio Realtek ALC897|LAN 2.5 Gigabit|RAID SATA 0, 1, 10; NVMe 0, 1, 10|TPM Header |
| HDMI | 1 |
| HDMI ports quantity | 1 |
| Included Accessories | - 1 x User Manual- 2 x SATA Data Cables- 2 x Screws for M.2 Sockets |
| Integrated audio | Realtek ALC897 |
| Integrated LAN | 2.5 Gigabit |
| Integrated video | Depending on CPU |
| iOS | 1 |
| LAN controller | Realtek RTL8125-BG |
| Line-in | Yes |
| Maximum internal memory | 64 GB |
| Memory slots | 2 |
| Memory slots type | DIMM |
| Memory type | DDR5 |
| Microphone | 1 |
| Microphone in | Yes |
| Motherboard chipset | AMD B650 |
| Motherboard chipset family | AMD |
| Motherboard form factor | micro ATX |
| Number of M.2 (M) slots | 1 |
| Number of memory slots | 2 |
| Number of SATA III connectors | 4 |
| PCI Express x1 (Gen 4.x) slots | 1 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI-Express 4.0 16x | 2 |
| PCI-Express 4.0 1x | 1 |
| Processor manufacturer | AMD |
| Processor socket | Socket AM5 |
| RAID | SATA 0, 1, 10; NVMe 0, 1, 10 |
| RAID levels | 0/1/10 |
| RAID support | Yes |
| RJ45 | 1 |
| SATA | Yes |
| Shipping Box Depth | 28 |
| Shipping Box Height | 6.2 |
| Shipping box quantity | 1 |
| Shipping Box Weight | 1.21 |
| Shipping Box Width | 26 |
| Socket | SAM5 |
| Supported memory types | DDR5-SDRAM |
| Supported storage drive interfaces | M.2,SATA III |
| Supported storage drive types | HDD & SSD |
| Thunderbolt headers | 1 |
| TPM | Header |
| TPM connector | Yes |
| Unbuffered memory | Yes |
| Unit Brutto Volume | 0.004514 |
| Unit Gross Weight | 1.21 |
| Unit Net Weight | 1.1 |
| USB 2.0 | 4 |
| USB 2.0 connectors | 2 |
| USB 2.0 ports quantity | 4 |
| USB 3.2 | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
| USB-C | 1 |
| Vendor Homepage | www.asrock.com/mb/AMD/B650M-HDVM.2/index.asp |
| Width | 244 mm |
| WiFi | No |
| Windows operating systems supported | Windows 10 x64/Windows 11 x64 |
