Product code: 1433280
Available quantity 7
| Warranty: | 36 |
| Manufacturer: | ASROCK |
| Technical specification | |
|---|---|
| 12V power connector | Yes |
| 1st M.2 highest PCI Express generation | 5.0 |
| 1st M.2 largest key size | 2280 |
| 2nd M.2 highest PCI Express generation | 4.0 |
| 2nd M.2 largest key size | 2280 |
| 3rd M.2 highest PCI Express generation | 4.0 |
| 3rd M.2 largest key size | 2280 |
| ATX Power connector (24-pin) | Yes |
| Audio chip | Realtek ALC897 |
| Audio output channels | 7.1 channels |
| Audio-In | 1 |
| Audio-Out | 1 |
| BIOS memory size | 256 Mbit |
| BIOS type | UEFI AMI |
| Cables included | SATA |
| Certification | FCC, CE, ErP/EuP |
| Chipset | AMD B850 |
| Compatible processor series | AMD Ryzen 7000 Series/AMD Ryzen 8000 Series/AMD Ryzen 9000 Series |
| Component for | PC |
| CPU fan connector | Yes |
| Depth | 244 mm |
| DisplayPort | 1 |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
| ECC сompatibility | ECC & Non-ECC |
| EPS power connector (8-pin) | Yes |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Form Factor | Micro-ATX |
| Frequency speed | 8000 |
| Front panel audio connector | Yes |
| Full Description Line | AMD B850|SAM5|Micro-ATX|DDR5|8000 MHz|Memory slots 4|1xPCI-Express 4.0 4x |1xPCI-Express 5.0 16x|1xM.2|1xHDMI|1xDisplayPort|1xAudio-In|1xAudio-Out|1xMicrophone|4xUSB 2.0|3xUSB 3.2|1xUSB-C|1xRJ45|SATA|USB-C|USB 2.0|USB 3.2|SATA 3.0|Video Depending on CPU|Audio Realtek ALC897|LAN 2.5 Gigabit|RAID SATA 0, 1, 10|TPM Header |
| HDCP | Yes |
| HDMI | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Headphone outputs | 3 |
| Integrated audio | Realtek ALC897 |
| Integrated LAN | 2.5 Gigabit |
| Integrated video | Depending on CPU |
| iOS | 1 |
| LAN controller | Dragon RTL8125BG |
| Line-in | Yes |
| Maximum internal memory | 256 GB |
| Maximum resolution | 3840 x 2160 pixels |
| Memory channels | Dual-channel |
| Memory slots | 4 |
| Memory slots type | DIMM |
| Memory type | DDR5 |
| Microphone | 1 |
| Microphone in | Yes |
| Motherboard chipset | AMD B850 |
| Motherboard chipset family | AMD |
| Motherboard form factor | micro ATX |
| Number of chassis fan connectors | 3 |
| Number of CPU fan connectors | 2 |
| Number of EPS power connectors (8-pin) | 1 |
| Number of M.2 (M) slots | 3 |
| Number of memory slots | 4 |
| Number of RGB LED pin headers | 1 |
| Number of SATA III connectors | 4 |
| Number of storage drives supported | 7 |
| Parallel processing technology support | Not supported |
| PCI Express x16 (Gen 5.x) slots | 1 |
| PCI Express x4 (Gen 4.x) slots | 1 |
| Processor manufacturer | AMD |
| Processor socket | Socket AM5 |
| Product colour | Black |
| RAID | SATA 0, 1, 10 |
| RAID levels | 0/1/10 |
| RAID support | Yes |
| RGB LED pin header | Yes |
| RJ45 | 1 |
| SATA | Yes |
| SATA 3.0 | Yes |
| Screws included | Yes |
| Shipping Box Depth | 54.5 |
| Shipping Box Height | 32 |
| Shipping box quantity | 1 |
| Shipping Box Weight | 13.4 |
| Shipping Box Width | 31 |
| Socket | SAM5 |
| Supported memory types | DDR5-SDRAM |
| Supported processor sockets | Socket AM5 |
| Supported storage drive interfaces | PCI Express 4.0,PCI Express 5.0,SATA III |
| Supported storage drive types | HDD & SSD |
| TPM | Header |
| TPM connector | Yes |
| Unbuffered memory | Yes |
| Unit Brutto Volume | 0.01155 |
| Unit Gross Weight | 2.3 |
| Unit Net Weight | 1.3 |
| USB 2.0 | Yes |
| USB 2.0 connectors | 2 |
| USB 2.0 ports quantity | 4 |
| USB 3.2 | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB connector type | USB Type-A/USB Type-C |
| USB-C | Yes |
| Vendor Homepage | www.asrock.com/MB/AMD/B850M%20Pro-A/index.asp |
| Width | 244 mm |
| WiFi | No |
| Windows operating systems supported | Windows 10 x64/Windows 11 x64 |
