Product code: 1394437
Available quantity 8
| Warranty: | 36 |
| Manufacturer: | DAHUA |
| Technical specification | |
|---|---|
| 15pin D-sub | 2 |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Alarm In | 16 |
| Alarm input channels | 16 |
| Alarm Out | 6 |
| Alarm output channels | 6 |
| Audio formats supported | G.711 A-law/G.726/PCM |
| Audio RCA inputs | 1 |
| Audio RCA outputs | 1 |
| Built-in processor | Yes |
| Certification | FCC: 47 CFR FCC Part15, SubpartB, Class A CE-EMC: EN 55032: 2015+A1: 2020; EN IEC 61000-3-2: 2019+A1: 2021; EN 61000-3-3: 2013+A1: 2019+A2: 2021;EN 55035: 2017+A11: 2020; EN 50130-4: 2011+A1: 2014 CE-LVD: EN 62368-1: 2014 |
| CPU | Industrial-grade processor |
| Depth | 415.1 mm |
| Desktop/pedestal | Yes |
| Dimensions | 440.0 × 415.1 x 70.0mm |
| DVI ports quantity | 2 |
| eSATA | Yes |
| eSATA ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Ethernet LAN data rates | 10/100/1000 Mbit/s |
| Face detection | Yes |
| Full Description Line | Channels 32|Drives/bays 4|Desktop/pedestal|Rack 1.5U|CPU Industrial-grade processor|SATA|Integrated LAN Gigabit|2x15pin D-sub|2xHDMI|1xRS232|4xUSB 2.0|2xRJ45|1xRS-485|16xAlarm In|6xAlarm Out|Power supply requirements 100–240 VAC, 50-60 Hz|Power consumption 13 Watts|Dim. 440.0 × 415.1 x 70.0mm |
| HDD Capacity | 0 GB |
| HDD interface | SATA III |
| HDMI | 2 |
| HDMI ports quantity | 2 |
| Height | 70 mm |
| Integrated LAN | Gigabit |
| iOS | 4 |
| Maximum resolution | 1920 x 1080 pixels |
| Maximum storage capacity | 16 TB |
| Multi-screen | Yes |
| Number of channels | 32 |
| Number of fans | 1 fan(s) |
| Number of HDDs supported | 4 |
| Operating relative humidity (H-H) | 10 - 93 % |
| Operating system installed | Embedded LINUX |
| Operating temperature (T-T) | -10 - 55 °C |
| Package depth | 500 mm |
| Package height | 210 mm |
| Package weight | 6110 g |
| Package width | 530 mm |
| Power consumption | 13 |
| Power consumption (typical) | 13 W |
| Power supply requirements | 100–240 VAC, 50-60 Hz |
| Product colour | Black |
| Rack 1.5U | Yes |
| Rack capacity | 1.5U |
| Rack mounting | Yes |
| RJ45 | 2 |
| RS-232 interface | Yes |
| RS-485 | 1 |
| RS-485 ports | 1 |
| RS232 | 1 |
| SATA | Yes |
| Shipping Box Depth | 52.5 |
| Shipping Box Height | 20.5 |
| Shipping box quantity | 1 |
| Shipping Box Weight | 6.55 |
| Shipping Box Width | 50 |
| Storage temperature (T-T) | -20 - 60 °C |
| Supported network protocols | HTTP; HTTPS; TCP/IP; IPv4/IPv6; RTSP; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; PPPoE; FTP; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration |
| Unit Brutto Volume | 0.05381 |
| Unit Gross Weight | 6.55 |
| Unit Net Weight | 4.74 |
| USB 2.0 | 4 |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Vendor Homepage | www.dahuasecurity.com/products/All-Products/Network-Recorders/WizSense-Series/NVR-5-EI-Series/4HDD/NVR5432-EI |
| VGA (D-Sub) output ports | 2 |
| Video formats supported | H.264/H.264+/H.265/H.265+ |
| Video input channels | 32 channels |
| Video motion detection | Yes |
| Weight | 4740 g |
| Width | 440 mm |
| WiFi | No |
