- 1/2.7”4Megapixel progressive CMOS, 2880 × 1620 @ 20FPS
- Minimum illumination: 0.01 lux @ F2.0 (Color, 30 IRE); 0.001 lu x@ F2.0 (B/W, 30 IRE), 0 lux (Illuminator on)
- True Day/Night (ICR), BLC / HLC / True WDR 120dB /3D DNR
- 2.1 mm fixed lens (180°)
- Up to 15 meters Smart IR Illumination
- H.265; H.264; H.264B; MJPEG, Smart H.265+; Smart H.264+encoding, ONVIF (Profile S/Profile G/Profile T); CGI; P2P
- 1/1 Audio I/O, 1/1 Alarm I/O, Built-in MIC
- Micro SD card up to 256GB supported
- Metal case, IP67, IK10, -40°C~+60°C, PoE / 12VDC power, 7.7W max
- Smart capabilities: Tripwire; intrusion (Recognition of human and vehicle).
- Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. SMD 3.0
- Free IP monitoring software available
| Techninė specifikacija |
| Alarm In |
1 |
| Alarm Out |
1 |
| Audio-In |
1 |
| Audio-Out |
1 |
| Camera design |
Dome |
| Dimensions |
94 mm × Φ122.0 mm |
| Environment |
Outdoor |
| Focal length |
2.1 mm |
| Full Description Line |
Type Fixed Dome/Outdoor|Pixel Resolution 4 Mega Pixel|Focal Length 2.1 mm|IR Illumination|Sensor size 1/2.7" CMOS|Microphone Built-in|Lens Mount M12|Min. Illumination 0.001 Lux|1xAudio-In|1xAudio-Out|1xMicroSD Card Slot|1xRJ45|1xAlarm In|1xAlarm Out|Supports card capacities up to 256GB|Power options PoE/12V|Power supply requirements PoE / 12VDC power|Environment Outdoor|Operating temperature range -40°C~+60°C|Dimensions 94 mm × Φ122.0 mm |
| IR Illumination |
Yes |
| Lens Mount |
M12 |
| MicroSD Card Slot |
1 |
| Microphone |
Built-in |
| Min. Illumination |
0.001 |
| Operating temperature range |
-40°C~+60°C |
| Pixel Resolution |
4 |
| Power consumption |
7.7 |
| Power supply requirements |
PoE / 12VDC power |
| RJ45 |
1 |
| Sensor size |
1/2.7" CMOS |
| Shipping Box Depth |
19 |
| Shipping Box Height |
19 |
| Shipping Box Weight |
0.775 |
| Shipping Box Width |
16 |
| Shipping box quantity |
1 |
| Supports card capacities up to |
256GB |
| Unit Brutto Volume |
0.005776 |
| Unit Gross Weight |
0.775 |
| Unit Net Weight |
0.5 |
| Vendor Homepage |
www.dahuasecurity.com/ceen/products/All-Products/Network-Cameras/WizSense-Series/3-Series/Wide-Angle/IPC-HDBW3441R-AS-P |
| iOS |
12V/PoE |
