1/3” 4 Megapixel progressive CMOS, 2560 × 1440 @20 fps
2.8 mm fixed lens (90 °)
Min. Illumination: 0.025 lux@ F2.0 (Color,30 IRE); 0.0025 lux@ F2.0 (B/W,30 IRE); 0 lux (Illuminator on)
Up to 30 meters IR Illumination
True Day/Night with ICR Filter, BLC, HLC, DWDR, 3D DNR
Smart H.265+; Smart H.264+, H.264B; H.264; H.264H; H.265, ONVIF (Profile S/Profile G); CGI; P2P
Wi-Fi: IEEE802.11b/g/n 2.4~2.4835GHz, up to 80 m
Micro SD Slot (up to 256 GB)
DC 12V1A Power supply, Power Consumption: < 4.9W
Bullet design, metal case, IP67, -40°C to +50°C, indoor/outdoor use
Free IP monitoring software available
| Techninė specifikacija |
| Camera design |
Dome |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Environment |
Outdoor |
| Focal length |
2.8 mm |
| Full Description Line |
Type Fixed Dome/HDTV/Megapixel/Outdoor|Pixel Resolution 4 Mega Pixel|Focal Length 2.8 mm|IR Illumination|Sensor size 1/3” 4|Microphone Built-in|Lens Mount M12|Min. Illumination 0.025 Lux|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xMicroSD Card Slot|Power options 12V|Power supply requirements DC 12V1A|Environment Outdoor|Operating temperature range -40°C to +50°C |
| IR Illumination |
Yes |
| Lens Mount |
M12 |
| MicroSD Card Slot |
1 |
| Microphone |
Built-in |
| Min. Illumination |
0.025 |
| Operating temperature range |
-40°C to +50°C |
| Pixel Resolution |
4 |
| Power consumption |
4.9 |
| Power supply requirements |
DC 12V1A |
| Sensor size |
1/3” 4 |
| Shipping Box Depth |
14 |
| Shipping Box Height |
14.5 |
| Shipping Box Weight |
0.639 |
| Shipping Box Width |
12.5 |
| Shipping box quantity |
1 |
| Unit Brutto Volume |
0.002537 |
| Unit Gross Weight |
0.639 |
| Unit Net Weight |
0.414 |
| Vendor Homepage |
www.dahuasecurity.com/products/All-Products/Network-Cameras/Wireless-Series/Wi-Fi-Series/4MP/IPC-HDBW1430DE-SW |
| iOS |
12V |
