- 1/2.9 ” CMOS; 2688x1520 @ 20FPS
- Minimum illumination: 0.008 lux @ F1.5(Color,30IRE); 0.0008 lux @ F1.5(B/W,30IRE); 0 lux (Illuminator on)
- True Day/Night (ICR), BLC/ HLC/ True WDR(120dB) / 3D DNR
- 2.7 mm–13.5 mm variocal lens (104°–29°)
- Up to 40 meters IR Illumination, Smart IR
- ONVIF (Profile S/Profile T); CGI; P2P; Milestone
- SD Card slot 256 GB max, Built-in MIC
- Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
- Eyeball design, Metal case, IP67, -30°C~+60°C, PoE / 12VDC power. 6.1 W max
- Free IP monitoring software available
| Techninė specifikacija |
| Camera design |
Eyeball |
| Dimensions |
108.3 mm × Φ122 mm |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Environment |
Outdoor |
| Focal length |
2.7 mm–13.5 mm |
| Full Description Line |
Type Outdoor|Pixel Resolution 4 Mega Pixel|Focal Length 2.7 mm–13.5 mm|IR Illumination|Sensor size 1/2.9 ” CMOS|Microphone Built-in|Min. Illumination 0.0008 Lux|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xMicroSD Card Slot|1xRJ45|Supports card capacities up to 256GB|Power options PoE/12V|Power supply requirements PoE / 12VDC power|Environment Outdoor|Operating temperature range -30°C~+60°C|Dimensions 108.3 mm × Φ122 mm |
| IR Illumination |
Yes |
| MicroSD Card Slot |
1 |
| Microphone |
Built-in |
| Min. Illumination |
0.0008 |
| Operating temperature range |
-30°C~+60°C |
| Pixel Resolution |
4 |
| Power consumption |
6.1 |
| Power supply requirements |
PoE / 12VDC power |
| RJ45 |
1 |
| Resolution |
4 |
| Sensor size |
1/2.9 ” CMOS |
| Shipping Box Depth |
16 |
| Shipping Box Height |
13.5 |
| Shipping Box Weight |
0.86 |
| Shipping Box Width |
15.5 |
| Shipping box quantity |
1 |
| Supports card capacities up to |
256GB |
| Unit Brutto Volume |
0.003348 |
| Unit Gross Weight |
0.86 |
| Unit Net Weight |
0.69 |
| Vendor Homepage |
www.dahuasecurity.com/ceen/products/All-Products/Network-Cameras/WizSense-Series/2-Series/4MP/IPC-HDW2441T-ZS |
| iOS |
12V/PoE |
