1/2.7”5Megapixel progressive CMOS, 2960 × 1668 @20FPS
Minimum illumination: 0.005 lux @ F1.4 (Color, 30 IRE)
True Day/Night (ICR), BLC / HLC / True WDR 120dB /3D DNR
2.8 mm fixed lens (111°)
Up to 30 meters Smart IR Illumination
H.265; H.264; H.264H; H.264B; MJPEG encoding, ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
Built-in MIC, G.711a; G.711Mu; PCM; G.726; G.723 encoding
Micro SD card up to 256GB supported
1/1 audio IO, / Alarm I/O
Metal case, IP67, IK10, -40°C~+60°C, PoE / 12VDC power, 5.9W max
Smart capabilities: Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)
Free IP monitoring software available
| Techninė specifikacija |
| Alarm In |
1 |
| Alarm Out |
1 |
| Audio-In |
1 |
| Audio-Out |
1 |
| Camera design |
Dome |
| Colour |
White |
| Dimensions |
64.8 mm × Φ111.0 mm |
| Effective pixels |
2960 (H) × 1668 (V) |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Environment |
Outdoor |
| Focal length |
2.8 mm |
| Full Description Line |
Type Fixed Dome/HDTV/Megapixel/Outdoor|Pixel Resolution 5 Mega Pixel|Focal Length 2.8 mm|IR Illumination|Sensor size 1/2.7”|Min. Illumination 0.005 Lux|Effective pixels 2960 (H) × 1668 (V)|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xAudio-In|1xAudio-Out|1xRJ45|1xAlarm In|1xAlarm Out|Supports card capacities up to 256GB|Power supply requirements 12 VDC/PoE (802.3af)|Environment Outdoor|Operating temperature range -40°C~+60°C|Colour White|Dimensions 64.8 mm × Φ111.0 mm |
| IR Illumination |
Yes |
| Min. Illumination |
0.005 |
| Operating temperature range |
-40°C~+60°C |
| Pixel Resolution |
5 |
| Power consumption |
5.9 |
| Power supply requirements |
12 VDC/PoE (802.3af) |
| RJ45 |
1 |
| Sensor size |
1/2.7” |
| Shipping Box Depth |
14 |
| Shipping Box Height |
12 |
| Shipping Box Weight |
0.57 |
| Shipping Box Width |
14 |
| Shipping box quantity |
1 |
| Supports card capacities up to |
256GB |
| Unit Brutto Volume |
0.002352 |
| Unit Gross Weight |
0.57 |
| Unit Net Weight |
0.423 |
| Vendor Homepage |
www.dahuasecurity.com/products/All-Products/Network-Cameras/WizSense-Series/3-Series/5MP/IPC-HDBW3541F-AS-S2 |
| iOS |
Fixed Dome/HDTV/Megapixel/Outdoor |
