>1/2.7" CMOS image sensor, low luminance, and high definition image.
>Outputs max. 6 MP (3288×1850) @20 fps, and supports 2688×1520 (2688 × 1520) @25/30 fps.
>H.265 codec, high compression rate, ultra-low bit rate.
>Built-in warm light and IR LED, the max. IR distance is 30 m and the max. warm light distance is 30 m.
>ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
>Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
>Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).
>Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
>Supports max. 256 G Micro SD card; built in Mic.
>12 VDC/PoE power supply, easy for installation.
>IP67 protection.
>SMD Plus.
>Focal Length 2.8 mm. Field of View 112°
| Techninė specifikacija |
| Camera design |
Bullet |
| Dimensions |
169.8 mm × 70 mm × 70 mm |
| Effective pixels |
3288 (H) × 1850 (V) |
| Electronic Shutter Speed |
Auto/Manual |
| Environment |
Outdoor |
| Focal length |
2.8 mm |
| Lens Mount |
M12 |
| Microphone |
Built-in |
| Min. Illumination |
0 |
| Operating temperature range |
–40 °C to +60 °C |
| Pixel Resolution |
6 |
| Power consumption |
4 |
| Power supply requirements |
12 VDC; PoE |
| RJ45 |
1 |
| Sensor size |
1/2.7" |
| Supports card capacities up to |
256GB |
| Vendor Homepage |
www.dahuasecurity.com/products/All-Products/Network-Cameras/WizSense-Series/2-Series/Smart-Dual-Light/IPC-HFW2649S-S-IL |
| iOS |
12V/PoE |
