> Intelligent PoE
> BT 90W
> 8-pin assignment PoE power supply
> Long distance PoE
> PoE watchdog
> Wide working temperature
Port 1–8: 8 × RJ-45 10/100 Mbps (PoE)
Port 9: 1 × RJ-45 10/100/1000 Mbps (Uplink)
Capacity: 3.6 Gbps
Packet Forwarding Rate: 2.678 Mbps
Communication Standard: IEEE802.3/IEEE802.3u/IEEE 802.3ab/IEEE802.3x
PoE Standard: IEEE802.3af/ IEEE802.3at/ Hi-PoE/ IEEE802.3bt
PoE Power: 96W
250 m long distance PoE transmission
| Techninė specifikacija |
| 10Base-T / 100Base-TX / 1000Base-T |
1 |
| Desktop/pedestal |
Yes |
| Dimensions |
190 mm × 100 mm × 30 mm |
| Forwarding rate |
2.678 |
| Full Description Line |
Type L2|Desktop/pedestal|Rack|1x10Base-T / 100Base-TX / 1000Base-T|IEEE 802.3|IEEE 802.3ab|IEEE 802.3u|IEEE 802.3x|PoE ports 8|PoE power budget 96 Watts|Switching capacity 3.6 Gbps|Forwarding rate 2.678 Mpps|Dimensions 190 mm × 100 mm × 30 mm|Unit Net Weight 0.47 kg |
| IEEE 802.3 |
Yes |
| IEEE 802.3ab |
Yes |
| IEEE 802.3u |
Yes |
| IEEE 802.3x |
Yes |
| PoE ports |
8 |
| PoE power budget |
96 |
| Primary port count |
9 |
| Rack |
Yes |
| Shipping Box Depth |
27 |
| Shipping Box Height |
24 |
| Shipping Box Weight |
1.253 |
| Shipping Box Width |
8 |
| Shipping box quantity |
1 |
| Switch type |
L2 |
| Switching capacity |
3.6 |
| Unit Brutto Volume |
0.005184 |
| Unit Gross Weight |
1.25 |
| Unit Net Weight |
0.47 |
| Vendor Homepage |
www.dahuasecurity.com/products/All-Products/Transmission/PoE-Switches/Desktop-PoE-Switch/PFS3009-8ET1GT-96 |
