- Intelligent PoE
- 8-pin assignment PoE power supply
- Long distance PoE
- PoE watchdog
- Wide working temperature
- PoE Power 96 W
- Port 1–8: 8 × RJ-45 10/100 Mbps (PoE)
- Port 9-10: 2 × RJ-45 10/100/1000 Mbps (Uplink)
- Communication Standard: IEEE802.3/IEEE802.3u/IEEE 802.3ab/IEEE802.3x
- PoE Standard: IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt
| Techninė specifikacija |
| Desktop/pedestal |
Yes |
| Dimensions |
190 × 100 × 30mm |
| Forwarding rate |
4.17 |
| Full Description Line |
Desktop/pedestal|PoE ports 8|PoE power budget 96 Watts|Switching capacity 5.6 Gbps|Forwarding rate 4.17 Mpps|Dimensions 190 × 100 × 30mm|Unit Net Weight 0.5 kg |
| Model name |
PFS3010-8ET-96-V2 |
| PoE ports |
8 |
| PoE power budget |
96 |
| Primary port count |
8 |
| Shipping Box Depth |
16.8 |
| Shipping Box Height |
24.2 |
| Shipping Box Weight |
1.249 |
| Shipping Box Width |
6.5 |
| Shipping box quantity |
1 |
| Switching capacity |
5.6 |
| Unit Brutto Volume |
0.002643 |
| Unit Gross Weight |
1.25 |
| Unit Net Weight |
0.5 |
| Vendor Homepage |
www.dahuasecurity.com/products/productDetail/15591 |
