1/2.7" CMOS, 2880 × 1620 @ 25FPS max
Minimum Illumination: 0.005 Lux/F1.6, 30IRE, 0 Lux IR on
IR Distance: up to 30m
2.8 mm lens, angle of view: 111°
True Day / Night with ICR Filter, BLC / HLC / DWDR / 2D DNR
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Bullet design (plastic), IP67, outdoor/indoor use, -40°C~+60°C
Power 12 VDC, 3.7W max
| Techninė specifikacija |
| Camera design |
Bullet |
| Dimensions |
161.3mm×69.7mm×70.0mm |
| Electronic Shutter Speed |
PAL: 1/25s–1/100000s NTSC: 1/30s–1/100000s |
| Environment |
Outdoor |
| Focal length |
2.8mm |
| Full Description Line |
Type Fixed/HDTV/Megapixel/Outdoor|Video interface HDCVI|Sensor size 1/2.7"|Focal Length 2.8mm|Lens Mount M12|Electronic Shutter Speed PAL: 1/25s–1/100000s NTSC: 1/30s–1/100000s|Power supply requirements 12V ±30% DC|Dimensions 161.3mm×69.7mm×70.0mm |
| IR Illumination |
Yes |
| Lens Mount |
M12 |
| Pixel Resolution |
5 |
| Power consumption |
3.7 |
| Power supply requirements |
12V ±30% DC |
| Sensor size |
1/2.7" |
| Shipping Box Depth |
18.5 |
| Shipping Box Height |
8 |
| Shipping Box Weight |
0.28 |
| Shipping Box Width |
9.5 |
| Shipping box quantity |
1 |
| Unit Brutto Volume |
0.001406 |
| Unit Gross Weight |
0.28 |
| Unit Net Weight |
0.19 |
| Vendor Homepage |
www.dahuasecurity.com/products/All-Products/HDCVI-Cameras/Lite-Series/5MP/Starlight/HAC-HFW1500C(-A) |
| Video interface |
HDCVI |
| iOS |
12V |
