Minimum Illumination: 0.03Lux/F2.0, 30IRE, 0Lux IR on
IR Distance: up to 30m
2.8 mm lens, angle of view: 105°
1-channel BNC high definition video output / Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Built-in MIC
True Day / Night with ICR Filter, BLC / HLC / DWDR / DNR / Defog
Bullet design (metal), IP67, outdoor/indoor use, -40°C~+60°C
Power 12 VDC, 4.3W max
| Techninė specifikacija |
| BNC |
1 |
| Dimensions |
174.5mm×70.6mm×72.3mm |
| Effective pixels |
3840 (H)× 2160 (V) |
| Environment |
Outdoor |
| Focal length |
2.8 - 3.5mm |
| Full Description Line |
Type Outdoor|Video interface HDCVI|Focal Length 2.8mm|Lens Mount M12|Effective pixels 3840 (H)× 2160 (V)|Microphone Built-in|1xBNC|Dimensions 174.5mm×70.6mm×72.3mm |
| Lens Mount |
M12 |
| Microphone |
Built-in |
| Min. Illumination |
0 |
| Pixel Resolution |
8 |
| Power consumption |
4.3 |
| Shipping Box Depth |
55.5 |
| Shipping Box Height |
23 |
| Shipping Box Weight |
10.3 |
| Shipping Box Width |
43.5 |
| Shipping box quantity |
20 |
| Unit Brutto Volume |
0.002776 |
| Unit Gross Weight |
0.515 |
| Unit Net Weight |
0.35 |
| Vendor Homepage |
www.dahuasecurity.com/products/All-Products/HDCVI-Cameras/Lite-Series/4K/Real-time/HAC-HFW1800T/T-A |
| Video interface |
HDCVI |
| iOS |
12V |
